SAK-XC2388E-136F128LR AA
END OF LIFE
discontinued
RoHS Compliant
Lead-free

SAK-XC2388E-136F128LR AA

END OF LIFE
Datasheet
package

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

SAK-XC2388E-136F128LR AA
SAK-XC2388E-136F128LR AA
Datasheet


Product details

  • A/D Input Lines (incl. FADC)
    24
  • Additional Features
    instruction cache
  • Budgetary Price €/1k
    16.54
  • CAN Nodes
    3
  • Digital I/O Pins
    118
  • DMA Channels
    16
  • DSP Functionality
    Yes
  • EEPROM Emulation
    Yes
  • External Bus Interface
    Yes
  • Fast Flash Programming
    Yes
  • Floating Point Unit
    No
  • I/O Operation Voltages
    3.3 V, 5 V
  • Instruction Width ([bits])
    16/32
  • Number of ADC Modules
    2
  • On-chip Clock Generation
    Yes
  • On-chip Voltage Regulator
    Yes
  • Oscillator Watchdog
    Yes
  • Power Mode
    2
  • Program Memory
    1088 kByte
  • Qualification
    Automotive
  • Real Time Clock
    Yes
  • Serial I/O Interfaces
    4
  • SRAM (incl. Cache)
    90 kByte
  • Temperature
    -40 to 125°C
  • Timed I/O Pins (PWM, CAPCOM)
    32
  • Timer/Counter
    17
  • Touch/LED Matrix Control
    No
  • Type of Memory
    Flash
  • Type of Serial I/O Interfaces
    SPI, UART, FlexRay™, I²C, I²S, LIN, CAN
  • Watchdog Timer
    Yes

OPN
XC2388E136F128LRAAKXUMA1
Product Status discontinued
Infineon Package
PG-LQFP-144
Package Name N/A
Packing Size 1000
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Country of Assembly (CoA)
MY
Country of Diffusion (CoD)
DE

Product Status discontinued
Infineon Package
PG-LQFP-144
Package Name -
Packing Size 1000
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
Country of Assembly (CoA)
MY
Country of Diffusion (CoD)
DE
The XC2300E series, an extension of the XC2300 microcontroller family, focuses on Safety applications. With up to 30% performance boost from the integrated instruction cache (iCache) and up to 128MHz frequency, it suits automotive Safety applications like high-end Airbag, Electric Power-Steering (EPS), or Braking, needing higher performance or future improvements.

Features

  • Package: PG-LQFP-144
  • CAN Nodes: 3
  • Program Memory: 1,088.0 KByte
  • FlexRay™: 2
  • Type of Serial I/O Interfaces: SPI, LIN, UART, IIC or IIS
