Active and preferred
RoHS Compliant

BSC0911ND

Data Sheet
package
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

BSC0911ND
BSC0911ND
ea.
Data Sheet

Product details

  • Budgetary Price €/1k
    0.59
  • Ciss
    3800 pF, 1200 pF
  • Coss
    470 pF, 1400 pF
  • ID (@25°C) max
    40 A, 40 A
  • IDpuls max
    160 A
  • Operating Temperature
    -55 °C to 150 °C
  • Package
    Asymmetrical Dual 5x6
  • Polarity
    N
  • Ptot max
    2.5 W
  • QG (typ @4.5V)
    7.7 nC, 25 nC
  • RDS (on) (@4.5V LL) max
    4.8 mΩ, 1.7 mΩ
  • RDS (on) (@10V) max
    1.2 mΩ, 3.2 mΩ
  • RDS (on) (@4.5V) max
    1.7 mΩ, 4.8 mΩ
  • RthJA max
    50 K/W
  • RthJC max
    1.5 K/W, 3.4 K/W
  • Rth
    1.5 K/W, 3.4 K/W
  • VDS max
    25 V, 25 V
  • VGS(th)
    1.6 V
Recommended
OPN
BSC0911NDATMA1
Product Status active and preferred
Infineon Package
PG-TISON-8
Package Name SuperSO8 5x6
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead-free No
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-TISON-8
Package Name SuperSO8 5x6
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
With the OptiMOS™ 25V product family, Infineon sets new standards in power density and energy efficiency for discrete power MOSFETs and system in package. Ultra low gate and output charge, together with lowest on-state resistance in small footprint packages, make OptiMOS™ 25V the best choice for the demanding requirements of voltage regulator solutions in servers, datacom and telecom applications. Available in halfbridge configuration (power stage 5x6).

Benefits

  • Save overall system costs by reducing the number of phases in multiphase converters
  • Reduce power losses and increase efficiency for all load conditions
  • Save space with smallest packages like CanPAK™, S3O8 or system in package solution
  • Minimize EMI in the system making external snubber networks obsolete and the products easy to design-in
