Active and preferred
RoHS Compliant

FF900R17ME7C

1700 V, 900 A halfbridge IGBT module
Data Sheet

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

FF900R17ME7C
FF900R17ME7C
Data Sheet

Product details

  • Configuration
    half-bridge
  • Dimensions (length)
    152 mm
  • Dimensions (width)
    62 mm
  • Features
    Solder pin
  • Housing
    EconoDUAL™ 3
  • IC(nom) / IF(nom)
    900 A
  • IC max
    900 A
  • Qualification
    Industrial
  • Technology
    IGBT7 - E7
  • VCE(sat) (Tvj=25°C typ)
    1.7 V
  • VCES / VRRM
    1700 V
  • VF (Tvj=25°C typ)
    2.55 V
  • Voltage Class max
    1700 V
Recommended
OPN
FF900R17ME7CBPSA1
Product Status active and preferred
Infineon Package AG-ECONOD
Package Name N/A
Packing Size 10
Packing Type TRAY
Moisture Level NA
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package AG-ECONOD
Package Name -
Packing Size 10
Packing Type TRAY
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
EconoDUAL™ 3 1700 V, 900 A halfbridge TRENCHSTOP™ IGBT7 module with emitter controlled 8 diode for best-in-class wind turbines.

Features

  • Latest emitter controlled diode
  • 3.4 kV isolation
  • Highest power density
  • Best-in-class VCEsat
  • Optimized switching losses
  • Enhanced controllability of dv/dt
  • Enhanced cosmic ray robustness
  • Improved terminals
  • Solder control pins
  • Integrated NTC temperature sensor
  • Isolated baseplate

Benefits

  • Highest output current in ED3 footprint
  • Less parallelization of the modules
  • Reduction of total system cost
