S25FS256TDACHC113
Active
RoHS Compliant

S25FS256TDACHC113

Datasheet
board
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

S25FS256TDACHC113
S25FS256TDACHC113
ea.
Datasheet

Product details

  • Density
    256 MBit
  • Family
    FS-T
  • Interface Bandwidth
    40 MByte/s
  • Interface Frequency (SDR/DDR) (MHz)
    80 / -
  • Interfaces
    Quad SPI
  • Lead Ball Finish
    Sn/Ag/Cu
  • Operating Temperature range
    0 °C to 70 °C
  • Operating Voltage range
    1.7 V to 2 V
  • Operating Voltage
    1.8 V
  • Peak Reflow Temp
    260 °C
  • Planned to be available until at least
    2030
  • Qualification
    Commercial
Recommended
OPN
S25FS256TDACHC113
Product Status active
Infineon Package SG-XFWLB-33
Package Name WLCSP
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package SG-XFWLB-33
Package Name WLCSP
Packing Size 5000
Packing Type TAPE & REEL
Moisture Level 1
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
S25FS256TDACHC113 is a 256 Mbit FS-T NOR Flash for code and data storage over Quad SPI. It operates from 1.7 V to 2.0 V across 0°C to 70°C (commercial) and supports SDR reads up to 80 MHz, with up to 40 MByte/s interface bandwidth. Built-in ECC corrects 1-bit and detects 2-bit errors, with SFDP plus unique ID, RD/BY# status, and RESET#/CS# signaling reset options for robust boot memory.

Features

  • 45-nm MIRRORBIT™ 2-bit-per-cell
  • Uniform 64 KB or 128 KB sectors
  • Configurable sector architecture
  • 256 B or 512 B program buffer
  • SPI 1-1-1 and Quad 1-1-4,1-4-4
  • Up to 104 MHz clock operation
  • ECC on 16-byte data units
  • 1-bit correct, 2-bit detect (ECC)
  • ECC status via EDUS and ECSV regs
  • RD/BY# output for Ready/Busy
  • SafeBoot failure signature in STR1
  • CS# signaling reset + RESET# pin

Benefits

  • 2 bpc lowers cost per stored bit
  • Sector sizes match code vs data
  • Configurable map eases migration
  • Page buffer speeds firmware update
  • Quad I/O enables fast XIP reads
  • 104 MHz supports high throughput
  • ECC improves read data reliability
  • ECC flags speed fault isolation
  • RD/BY# reduces host firmware load
  • SafeBoot enables recovery after fault
  • Reset options improve robustness
  • SFDP support eases host bring-up
