TLE9954EQA40

MOTIX™ TLE9954EQA40 is the ultimate integrated solution for automotive auxiliary pumps and fans
Data Sheet
package
board
software
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLE9954EQA40
TLE9954EQA40
ea.
Data Sheet

Product details

  • Family
    MOTIX™ motor control SoCs
  • Frequency
    40 MHz
  • GPIO
    8
  • Interfaces
    PWM, LIN
  • Operational Amplifier
    Yes
  • Planned to be available until at least
    2039
  • PN MOS DRIVER
    No
  • RAM
    6 kByte
  • Supply Voltage range
    5.5 V to 29 V
  • Temperature range
    -40 °C to 150 °C
  • Temperature
    - 40°C - 150°C
Recommended
OPN
TLE9954EQA40XUMA1
Product Status active and preferred
Infineon Package
PG-TSDSO-32
Package Name N/A
Packing Size 3000
Packing Type TAPE & REEL
Moisture Level 2a
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-TSDSO-32
Package Name -
Packing Size 3000
Packing Type TAPE & REEL
Moisture Level 2a
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
The MOTIX™ TLE9954EQA40 is an integrated single-chip 3-phase motor driver with an Arm® Cortex®-M23 core, flash memory, analog or mixed-signal peripherals, LIN interface, and driving stages. The device complies with ISO 26262 up to ASIL B for functional safety. Additionally, it provides IP protection through Arm® TrustZone, enhancing security. The MOTIX™ TLE9954EQA40 is a perfect for BLDC motor drive applications, including pumps and fans.

Features

  • 32-bit Arm® Cortex®-M23, 40 MHz
  • Single power supply: 5.5 V to 29 V
  • On-chip clock generation
  • CRC engine for data integrity
  • 72 KB flash, EEPROM emulation, 6 KB RAM
  • LIN protocol support (LINUART)
  • High voltage monitoring pin (MON)
  • Fast synchronous communication (SSC)
  • Three-phase bridge driver (BDRV)
  • Low-side shunt current sense amp
  • Temperature range, TJ: -40°C to 150°C
  • TSDSO-32 package

Benefits

  • Improved hardware features
  • Functional safety (ASIL B)
  • Cybersecurity (TrustZone)
  • Premium design-in experience
  • FOC capability
  • Competitive price range

Applications
