TLE8457CSJ

The TLE8457CSJ is a monolithic integrated LIN transceiver with low drop-out voltage regulator in the TSON-8 package.
Data Sheet
package
board
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLE8457CSJ
TLE8457CSJ
ea.
Data Sheet

Product details

  • Additional Features
    5.0 V output VREG, EN, RESET
  • Bus Wake-Up Capability
    Yes
  • Family
    LIN Transceiver
  • Features
    Integrated voltage regulator, EN
  • Green
    RoHS compliant, Halogen free
  • Output Current
    70 mA
  • Currently planned availability until at least
    2038
  • Qualification
    Automotive
  • Quiescent Current
    < 10 µA sleep mode
  • Standards
    LIN 1.2, 1.3, 2.x, 2.2A, SAEJ2602, ISO 17987-4
  • Supply Voltage
    5 V
  • Transmission Rate max
    20 kBit/s
  • Type
    LIN
  • Wake-up Inputs
    Bus wake-up
Recommended
OPN
TLE8457CSJXUMA1
Product Status active and preferred
Infineon Package
PG-DSO-8
Package Name N/A
Packing Size 2500
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package
PG-DSO-8
Package Name -
Packing Size 2500
Packing Type TAPE & REEL
Moisture Level 3
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
TLE8457CSJ supplies stable 5V (up to 70 mA) for microcontroller and peripherals. Offers protection, LIN 2.2A, SAE J2602 compliance. Ultra-low standby current (20 μA). Infineon BiCMOS technology for ESD robustness, EMC compliance. AEC qualified for automotive use. Various output voltages, packages, and features available in TLE8457 family.

Benefits

  • 5 V low drop-out linear voltage regulator with 70 mA current capability
  • stable output voltage with small ceramic output capacitor ( 1 µF )
  • integrated initialization time-out feature
  • low current consumption in stand-by mode (40 μA) and sleep mode (16μA)
  • includes the TxD dominant time-out feature
  • excellent EMC performance (IBEE test report)
  • DSO-8 package
  • TLE8457CSJ LIN-LDO demo board available
