Continuous innovation on various technology nodes has been the key enabler of new, innovative and advanced audio features for consumer electronics. Novel functionalities such as Active Noise Cancellation (ANC), transparent hearing, AI-assisted voice control or audio-zoom are just the beginning of an ongoing audio revolution driven by advances in audio processing algorithms, microelectronics and microelectromechanical systems (MEMS) sensors.

Infineon XENSIV™ MEMS microphones are at the forefront of this revolution by capturing audio signals with unprecedented detail and hence providing the best possible input for the audio signal processing chain. Our MEMS microphones feature ultra-low self-noise (high SNR), extremely low distortions (THD) even at high sound pressure level (SPL), very tight phase and sensitivity matching, a flat frequency response with a low LFRO (low frequency roll-off) and ultra-low group delay. Combined with selectable energy efficiency modes and their very small package size, Infineon XENSIV™ MEMS microphones are the perfect match for all portable consumer devices.

Navigate the “hearing”, “communication” and “recording” use-cases and browse through our product specs below to find the ideal match for your use case and to learn more about how XENSIV™ MEMS microphones can enable your device for the next generation of advanced audio features.

For additional information, visit our MEMS microphones for consumer product page. In case of questions, reach out to microphones@infineon.com.

New microphones coming soon!

lorem ipsum
lorem ipsum
lorem ipsum

Explore the product features and benefits of our brand new analog and digital MEMS microphones.







XENSIV™ analog microphones

                                                                  IM73A135



     Normal mode

     Low power mode

         Size [mm3]

                                   4.0 x 3.0 x 1.2

     Sound port [mm]

                                   0.6 (Bottom)

          Interface

                             Analog differential

          VDD [V]

            2.3 – 3.0

             1.52 – 1.8

     Sensitivity [dBV]

               -38

                -38

       SNR [dB(A)]

                73

                  71

         LFRO [Hz]

                20

                  20

    1% THD [dBSPL]

               132

                 124

       AOP [dBSPL]

               137

                 130

          IDD [μA]

               170

                  70

                                                               Product Brief

                                                         Typical applications

  • ANC headphones
  • Smart speakers
  • Conference systems

                                                                  IM70A135



     Normal mode

     Low power mode

         Size [mm3]

                                   3.5 x 2.65 x 1.0

     Sound port [mm]

                                   0.325 (Bottom)

          Interface

                             Analog differential

          VDD [V]

            2.3 – 3.0

             1.52 – 1.8

     Sensitivity [dBV]

               -38

                -38

       SNR [dB(A)]

                70

                  69

         LFRO [Hz]

                37

                  37

    1% THD [dBSPL]

               130

                 118

       AOP [dBSPL]

               135

                 120

          IDD [μA]

               170

                  70

                                                               Product Brief

                                                         Typical applications

  • TWS earbuds
  • ANC headphones
  • Wearables

XENSIV™ digital PDM microphones

                                                                   IM69D127



Normal mode

Low power mode

    Size [mm3]

                              3.6 x 2.5 x 1.0

  Sound port [mm]

                               0.6 (Bottom)

     Interface

                                  PDM

       VDD [V]

                              1.62 – 3.60

   PDM clock [kHz]

       3072

             768

   Sensitivity [dBV]

        -34

              -34

      SNR [dB(A)]

         69

               65

       LFRO [Hz]

         40

               40

  1% THD [dBSPL]

       123

            123

     AOP [dBSPL]

       127

            127

        IDD [μA]

       980

            300

                                                            Product Brief

                                                         Typical applications

  • ANC headphones
  • Smart speakers
  • Conference systems
  • Wearables

                                                                    IM72D128



Normal mode

Low power mode

    Size [mm3]

                              4.0 x 3.0 x 1.2

  Sound port [mm]

                               0.6 (Bottom)

     Interface

                                  PDM

       VDD [V]

                              1.62 – 3.60

   PDM clock [kHz]

       3072

             768

   Sensitivity [dBV]

        -36

              -36

      SNR [dB(A)]

         72

               67

       LFRO [Hz]

         20

               20

  1% THD [dBSPL]

       126

            126

     AOP [dBSPL]

       128

            128

        IDD [μA]

       980

            280

                                                                  Product Brief

                                                         Typical applications

  • ANC headphones
  • Smart speakers
  • Conference systems
  • Laptop / Tablets

                                                                   IM73D122



Normal mode

Low power mode

    Size [mm3]

                              4.0 x 3.0 x 1.2

  Sound port [mm]

                               0.6 (Bottom)

     Interface

                                  PDM

       VDD [V]

                              1.62 – 3.60

   PDM clock [kHz]

       3072

             768

   Sensitivity [dBV]

        -26

              -26

      SNR [dB(A)]

         73

               69

       LFRO [Hz]

         20

               20

  1% THD [dBSPL]

       120

            120

     AOP [dBSPL]

       122

            122

        IDD [μA]

       980

            280

                                                              Product Brief

                                                         Typical applications

  • Smart speakers
  • Conference systems
  • Laptop / Tablets

Brilliant hearing with XENSIV™ MEMS microphones

lorem ipsum
lorem ipsum
lorem ipsum

Differentiate your TWS hearable, headphone or headset device with Infineon’s XENSIV™ MEMS microphone to give your customers the best possible listening experience. An ultra-high SNR, a very low LFRO (low frequency roll-off), ultra-low latency and a very high acoustic overload point (AOP) enable best-in-class active noise cancellation and transparent hearing functionality under all conditions.

Binaural listening experience with Infineon MEMS microphones

Immerse yourself in a virtual sound stage! A human auditory system is simulated by placing two Infineon high performance MEMS microphones in the ears of an artificial head. These are connected to an Infineon Audiohub Nano board that sends the recorded sound directly to your headphone. Because of the low self-noise of the microphones, it feels like you are listening with your own ears and are right were the action is!



Noise-free communication with our XENSIV™ MEMS microphones

lorem ipsum
lorem ipsum
lorem ipsum

Ultra-low self-noise, very high AOP and very tight phase and sensitivity matching makes Infineon’s XENSIV™ MEMS microphones especially suited for high-quality audio communication in all environments. Improve the phone call and online-meeting experience of your customers by capturing crystal clear, noise-free audio and by combining multiple microphones in an array and thus selecting only relevant audio sources with beamforming and source separation techniques in your smart phone, hearable, laptop or conference speaker products.

High-quality recording with our XENSIV™ MEMS microphones

lorem ipsum
lorem ipsum
lorem ipsum

Transform your smart phone, camera, headset or smart speaker into a state-of-the-art recording device by implementing Infineon’s XENSIV™ MEMS microphones. Our ultra-low noise microphones enable reliable voice pickup at maximum range for AI-assisted voice control units and the very tight phase and sensitivity matching of our parts enable advanced beamforming techniques for multi-user voice pickup and audio zoom features.



Experience high performance Infineon XENSIV™ MEMS microphone

What is the difference between a high and a low performance MEMS microphone? Hear for yourself! In this demonstrator, we focus on a microphone’s dynamic range, which describes how well microphones can record quiet as well as very loud sounds. The upper limit of a microphone’s dynamic range is defined as the Acoustic Overload Point (AOP) - the maximum volume a signal can have before the physical limits of the microphone are reached. The lower limit is defined by the microphone’s self-noise level, or Signal to Noise ratio (SNR). A microphone can only record sounds above its self-noise level. Here, you will get to hear how recordings sound differently based on whether you use a low or a high dynamic range microphone.

Support

For more information on the best microphone for your design, contact us at microphones@infineon.com

Audio Hub Nano: Plug & play studio quality audio recordings with XENSIV™ MEMS microphones

XENSIV™ MEMS microphones are ubiquitous in today’s consumer devices – these powerful, yet small microphones are the ears of smartphones, earbuds and other electronics. With the IM69D130, Infineon has set a new performance benchmark in MEMS microphones. But how can you use them if you haven’t laid out your system yet? When you cannot solder right now, how can you verify the performance of a MEMS microphone? The Infineon Audio Hub Nano allows you to do just that, and more: In this video, you will learn how to start recording just by plugging our evaluation board into your laptop or even smartphone!
