not for new design
RoHS Compliant

MCETOOLV2

Isolated iMOTION™ motor control IC debugger tool
User Manual
board
software

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

MCETOOLV2
MCETOOLV2
User Manual

Product details

  • Board Type
    Evaluation Board
  • Dimensions
    281x230mm
  • Family
    iMOTION™ Motor Control ICs, Microcontroller, Motor Driver
  • Input Type
    AC
  • Product Name
    Eval-M1-05-65D
  • Sub Application
    Fans, Home Appliances, Pumps
  • Target Application
    Automation, Motor Control & Drives, Industrial, Consumer
  • Topology
    3-Phase Motor
OPN
MCETOOLV2
Product Status not for new design
Infineon Package --
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level N/A
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:

Product Status not for new design
Infineon Package --
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level -
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
The MCETOOLV2 is a debugger tool for programming and debugging iMOTION™ ICs like IRMCK099, IRMCx100, and RMCx300 series. It also configures and tunes motor and inverter boards via UART to USB, supported by PC tools MCEWizzard and MCEDesigner. It's essential for the iMOTION™ Modular Application Design Kit platform. Check if the kit includes MCETOOL V2 or if it needs separate purchasing. Note: MCETOOLV2 replaces the obsolete MCETOOLV1.

Features

  • Programming of memory for IRMCxxxx
  • Debug. via standard JTAG interface
  • Confi. & tuning of via virtual UART
  • All interfaces galvanic. isolated
  • 3.3 VDC output voltage to target
  • Inter. gen. of OTP program. voltage
  • USB interf. to PC for power & data
  • Ships with all required cables

Benefits

  • Supports all iMOTION 1.0 devices
  • Integrated galvanic isolation
  • Compatible with MCEDesigner

Applications
