EVAL_10KW_3LANPC_SIC

Virtual evaluation board for ANPC 3-level topology using 400 V CoolSiC™ MOSFET
User Manual

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

EVAL_10KW_3LANPC_SIC
EVAL_10KW_3LANPC_SIC
User Manual

Product details

  • Board Type
    Virtual Design
  • Configuration
    3L ANPC
  • Description
    Virtual evaluation board for ANPC 3-level topology using 400 V CoolSiC™ MOSFET
  • Dimensions
    245x 145 x 50 mm (LxWxH)
  • Family
    MOSFET
  • Input Type
    DC
  • Output Current max
    16 A
  • Pout max
    10000 W
  • Supply Voltage
    400 V to 600 V
  • Target Application
    Energy storage, Industrial Drives, Motor control and drives, Solar string inverter, UPS
Recommended
OPN
EVAL10KW3LANPCSICTOBO1
Product Status active and preferred
Infineon Package --
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level N/A
Moisture Packing DRY
Lead-free No
Halogen Free No
RoHS Compliant No
Infineon stock last updated:

Product Status
Active
Infineon Package --
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level -
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
This virtual design for 3L-ANPC topologies features a 3-phase, 3-level inverter board and isolated power supply board. The optimized layout minimizes commutation loop inductance, reducing switching losses and voltage overshoot. It is ideal for engineers and researchers to experiment, validate, and optimize 3L-ANPC systems for industrial motor drives and photovoltaic string inverters.

Features

  • Test platform for 3L-ANPC topology
  • 3-phase, 3-level ANPC power board
  • Isolated power supply: AUX power supply
  • XMC4400 Drive card interface
  • High precision coreless current sensor
  • CoolSiC™ 400 V - heat-sink free design

Benefits

  • High efficiency > 99.5% & power density
  • Low EMI
  • Reduced voltage stress, improved longevity
  • Flexible motor control algorithm
  • Allows for 2-L modification to compare
  • Extended power range via heatsink (opt.)
