Active and preferred
RoHS Compliant
Lead-free

IRS2877C

REAL3™ Time-of-Flight (ToF) image sensor with HVGA system resolution

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

IRS2877C
IRS2877C

Product details

  • Ambient Temperature
    -40 °C to 85 °C
  • Applications
    Smartphones (Face authentication, Augmented reality, Computational photography), Smart door locks, Robotics
  • Classification
    Standard (JEDEC JESD22 J-STD-20)
  • Companion VCSEL driver
    IRS9102C
  • Package
    Bare die
  • Pixel amount
    640 x 480
  • Resolution (Pixel)
    307.2 K
  • Wavelength
    940 nm
Recommended
OPN
IRS2877CX1SA1
Product Status active and preferred
Infineon Package --
Package Name N/A
Packing Size 1
Packing Type WAFER SAWN
Moisture Level NA
Moisture Packing DRY
Lead-free Yes
Halogen Free Yes
RoHS Compliant Yes
Infineon stock last updated:

Product Status
Active
Infineon Package --
Package Name -
Packing Size 1
Packing Type WAFER SAWN
Moisture Level NA
Moisture Packing DRY
Lead Free
Halogen Free
RoHS Compliant
The REAL3™ IRS2877C is a 3D Time-of-Flight (ToF) image sensor tailored for the consumer and industrial markets. It provides a HVGA pixel resolution (~153k pixels), optimized interface, and an excellent depth performance-to-power consumption ratio. Thanks to its unique pixel layout, efficient up-scaling to VGA (307k) depth maps is enabled.
