CY8CKIT-149

PSOC™ 4100S Plus Prototyping Kit
User Manual
ea.
in stock

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CY8CKIT-149
CY8CKIT-149
ea.
User Manual

Product details

  • Bluetooth Standard
    BLE 5.0
  • Board Type
    Prototyping Kit
  • CapSense
    Buttons,Slider
  • Connectivity
    Bluetooth Low Energy, Single-mode BLE
  • Core
    Arm Cortex-M0+
  • External memory
    None
  • Family
    PSOC™ 4 Bluetooth® Low Energy, PSOC™ 4100S Plus Microcontroller
  • Features
    N/A
  • GPIOs/Shield Compatibility
    None
  • Hardware Compatibility
    N/A
  • Input Type
    DC
  • Programmer/Debugger
    Onboard KitProg
  • Programming/Bridging
    USB-Serial
  • Qualification
    Industrial, Consumer
  • Sensors
    None
  • Software Ecosystem
    Modus Toolbox
  • Software Support
    ModusToolbox,PSoC Creator
  • Target Application
    Industrial automation, Home entertainment, Wearables
  • WiFi Standard
    N/A
Recommended
OPN
CY8CKIT-149
Product Status active and preferred
Infineon Package N/A
Package Name N/A
Packing Size 1
Packing Type CONTAINER
Moisture Level NA
Moisture Packing NON DRY
Lead-free No
Halogen Free No
RoHS Compliant Yes
Infineon stock last updated:
 ea. in stock

Product Status
Active
Infineon Package N/A
Package Name -
Packing Size 1
Packing Type CONTAINER
Moisture Level NA
Moisture Packing NON DRY
Lead Free
Halogen Free
RoHS Compliant
ea.
in stock
The PSOC™ 4100S Plus Prototyping Kit is designed as an easy-to-use and inexpensive prototyping platform. The Prototyping Kit supports the PSOC™ 4100S Plus device, it offers an open footprint breakout board to maximize the end utility of the PSOC™ 4100S Plus. This kit provides a platform to easily develop integrate the PSOC™ 4100S Plus and low-power CAPSENSE™ solution. It is designed with a snap-away form-factor.

Features

  • PSOC™ 4100S Plus, 128KB Flash/16KB SRAM
  • Six Segment Capacitive Slider
  • Three mututla capsense buttons
  • Feedback LEDs
  • EZ-BLE Module with feedback LED
  • A push button for a user input
  • snap-away form-factor
  • On board KitProg2
  • USB 2.0 Micro-B Connector
  • Current Measurement Jumper

Benefits

  • 32-bit, 48-MHz ARM Cortex-M0+ CPU
  • 12-bit 1-Msps SAR ADC
  • Single-slope 10-bit ADC
  • Low Power 1.71 to 5.5-V Device Operation
  • Two opamps
  • Two current DACs
  • Two low-power comparators
  • Capacitive sensing
  • LCD drive capability
  • Eight 16-bit TCPWM block
  • CAN 2.0B block

Applications

Bill of Material

Documents

Documents

Design resources

Partner solutions

Developer community
